Development Goal

Mud Cross-Country Tyre

Performance Specification

Apply variable pitch shoulder design, matrix structure roughsidewall, super massive armor type and combination of fashional pattern design, this product provides excellent cross-country performance and meet the aesthetic bearing and many other aspects of demand.

Main Performance Product Size






1、Excellent Dirt Off-Road

Through the special pattern design, to enhance the mud cross-country performance greatly

A.The design of smaller sea grounding block area is relatively small (about 46%), transverse grooves ensure smooth, strong grip,and the tire to climb the slope is 65-70 degree slope easily.

B.Use the shoulder to shoulder design, a rough, massive and armor type sidewall, which ensures the mud and sand handling capabilities of the tyre, while effectively protecting against external damage during rough road driving.

















2、Super Carrying Capacity

Mainly through the structural design of the carcass, to maximize the bearing capacity

A.As for structure design, using the double crown wide steel belt and three layers of polyester cord, in order to further enhance the strength of the matrix in the belt surface and layers of nylon cord, effectively guarantee the strength requirement of tire pressure at rated load.

B.Besides the three ply cord, two ply cross ply cord is added, which gives the tyre superior puncture resistance and ensures the normal use in harsh environment.


















3、Excellent Wet Grip

Mainly optimize the pattern design, to enhance the performance of the tyre wet grip

A.Main channel volume increasing,can effectively make the formation of large drainage space between the tire and the road surface, the tyre can be concentrated to the middle of the water to a large number of rows, reducing bad effect, and enhance the safety of wet grip.








Series SIZE Load index Speed rating PR SW Extra Load Tread depth(MM) Max. pressure(kPa) Standard rim(ins)
55LT 285/55R22LT 124/121 Q 10 - 14.0  550 9J
65LT 275/65R20LT 126/123 Q 10 - 13.5  550 8J
70LT LT265/70R17 121/118 Q 10 B/W 12.5  550 8J
275/70R18LT 125/122 Q 10 - 14.0  550 8J
LT285/70R17 121/118 Q 8 - 12.5  450 8½J
LT305/70R16 118/115 Q 8 - 13.5  350 9J
75LT LT215/75R15 100/97 Q 6 - 12.5  350 6J
LT235/75R15 104/101 Q 6 B/W 12.5  350 6½J
LT245/75R16 120/116 Q 10 B/W 12.5  550 7J
LT265/75R16 123/120 Q 10 B/W 12.5  550 7½J
285/75R16LT 122/119 Q 8 - 12.5  450 8J
LT315/75R16 121 Q 8 - 14.0  350 8½J
80LT 185R14LT 102/100 Q 8 W 12.5  450 5½J
30×9.50R15LT 104 Q 6 - 13.5  350 7½J
31×10.50R15LT 109 Q 6 B/W 13.5  350 8½J
33×12.50R15LT 108 Q 6 - 14.0  250 10J
35×12.50R15LT 113 Q 6 - 14.0  250 10J
33×12.50R17LT 120 Q 10 - 12.5  450 10J
35×12.50R17LT 121 Q 10 - 14.0  450 10J
33×12.50R18LT 118 Q 10 - 12.5  450 10J
35×12.50R18LT 123 Q 10 - 12.5  450 10J
33×12.50R20LT 114 Q 10 - 12.5  450 10J
35×12.50R20LT 121 Q 10 - 12.5  450 10J
33×12.50R22LT 109 Q 10 - 14.0  450 10J
35×12.50R22LT 117 Q 10 - 14.0  450 10J
37×13.50R17LT 121 Q 8 - 14.0  350 11J
37×13.50R20LT 127 Q 10 - 14.5  450 11J
37×13.50R22LT 123 Q 10 - 17.0  450 11J
37×13.50R24LT 120 Q 10 - 14.0  450 11J

* COMING SOON

All the data are subject to change by the manufacturer without further notice.
